15DCB10F

更新时间:2025-04-13 13:19:19

IC热门型号推荐优势：品质保障[放心]、稳定库存[安心]、优质商家[省心] 点击搜索体验

15DCB10F的中文资料和PDF资料下载 图文及资料仅供参考，以实际PDF为准

15DCB10F外观图

大小：242.17KB
厂家：TEC[TE Connectivity Ltd]
描述：DC Series DC Series RFI Power Line Filters for DC Applications 217 Corcom Product Guide DC Filters 4 Hipot rating (one minute): Line to Ground: 2250 VDC LIne to Line: 1450 VDC Rated Voltage (max): 80 VDC Rated Current: 15 to 125A Operating Ambient Temperature Range (at rated current I r ): -10°C to +55°C In an ambient temperature (T a ) higher than +55°C the maximum operating current (I o ) is calculated as follows: I o = I r ?(85-Ta)/30 UL Recognized CSA Certi?ed TUV Certi?ed ? General purpose line ?lters for DC applications up to 125VDC ? Available with or without a circuit breaker ? Available with feedthrough capacitors for added high frequency performance ? Available in both ?ange mound (DCF) and bulkhead mount (DCB) con?guration Ordering Information 60 DC B 6 B Options B – Circuit breaker F – Feedthrough capacitors BF – Circuit breaker and feedthrough F and BF available only in bulkhead (B) mounting style Omit for none Input / Output Styles 6 – Redundant stud 10 – Phoenix termi
制造商：TE Connectivity
产品种类：电源线滤波器
电压额定值：80 VoltsDC
电流额定值：15 A
安装风格：Bulkhead and Rack
过滤器类型：EMI/RFI Filter
过滤：Yes
产品：Power Line Filters
系列：DC (15-125 Amp)
工厂包装数量：2
零件号别名：4-6609074-2
