MICROCIRCUIT DATA SHEET

MNCLC409A-X REV 0A0

Original Creation Date: 08/05/98

Last Update Date: 02/24/99

Last Major Revision Date: 11/12/98

VERY WIDEBAND, LOW DISTORTION MONOLITHIC OP AMP

General Description

The CLC409 is a very wideband, DC coupled monolithic operational amplifier designed

specifically for wide dynamic range systems requiring exceptional signal fidelity.

Benefiting from Comlinear's current feedback architecture, the CLC409 offers a gain range

of +1 to +10 while providing stable, oscillation free operation without external

compensation, even at unity gain.

With its 350MHz small signal bandwidth (Vout = 2Vpp), 10-bit distortion levels through

20MHz (Rl = 100Ohms), 8-bit distortion levels through 60Mhz, 2.2nV/SqRtHz input referred

noise and 13.5mA supply current, the CLC409 is the ideal driver or buffer for high speed

flash A/D and D/A converters.

Wide dynamic range systems such as radar and communication receivers requiring a wideband

amplifier offering exceptional signal purity will find the CLC409's low input referred

noise and low harmonic and intermodulation distortion make it an attractive high speed

solution.

Industry Part Number

CLC409A

NS Part Numbers

CLC409AE-QML**

CLC409AJ-QML*

Prime Die

UB1927B

Controlling Document

5962-9203401MPA*, M2A**

Processing

MIL-STD-883, Method 5004

Subgrp Description

1

2

3

4

5

6

7

8A

8B

9

10

11

Static tests at

Static tests at

Static tests at

Dynamic tests at

Dynamic tests at

Dynamic tests at

Functional tests at

Functional tests at

Functional tests at

Switching tests at

Switching tests at

Switching tests at

Temp (

o

C)

+25

+125

-55

+25

+125

-55

+25

+125

-55

+25

+125

-55

Quality Conformance Inspection

MIL-STD-883, Method 5005

1
