Near-hermetic welded seal
Stainless-steel case
100 years expected operating life
New 2 inch case size
Speci铿乧ations
Operating Temperature:
Rated Voltage:
Capacitance:
Load Life:
Leakage Current:
Cold Impedance:
Ripple Current Multipliers:
鈥?5 掳C to +125 掳C
5.0 to 250 Vdc
220 to 47,000 碌F 卤20%
2,000 h @ +125 掳C
0.002 CV 碌A @ 25 掳C and 5 min
鈥?5 潞C multiple of 25 潞C Z is 鈮?10 for up to 20 V, 2 for
25 V to 250 V
Case Temperature
45 掳C 55 掳C 65 掳C 75 掳C 85 掳C 95 掳C 105 掳C 115 掳C 125 掳C
1.41
1.32
1.22
1.12
1.00
0.87
0.71
0.50
0.00
Ambient Temperature, No Heatsink
45 掳C 55 掳C 65 掳C 75 掳C 85 掳C 95 掳C 105 掳C 115 掳C 125 掳C
0.63
0.58
0.54
0.49
0.44
0.38
0.31
0.22
0.00
Frequency
50 Hz 60 Hz 120 Hz 360 Hz 1 kHz 5 kHz 10 kHz & up
5 to 40 V
0.95
0.96
0.84
1.00
1.00
1.03
1.18
1.04
1.25
1.04
1.30
1.04
1.30
60 to 250 V
0.80
EIA Ripple Life:
Shelf Life:
Thermal Resistance:
10,000 h full load at 85 C per EIA IS-749
螖 capacitance 卤10%
ESR 200% of limit
DCL 100% of limit
500 h at 125 掳C, capacitance, ESR & DCL, initial requirements
Large Sides Case Length
Heatsinked
Insulation
one
both
None
Polyester
None
Polyester
1.5"
潞C/W
3.3
4.5
2.8
4
2.0"
潞C/W
2.6
3.6
2.2
3.2
3.0"
潞C/W
1.3
1.8
1.1
1.6
RoHS-5 Compliant
Has more than 1000 ppm lead in
some homogenous material but
otherwise complies with the EU
Directive 2002/95/EC requirement
restricting the use of Lead (Pb),
Mercury (Hg), Cadmium (Cd),
Hexavalent chromium (Cr(VI)),
PolyBrominated Biphenyls (PBB)
and
PolyBrominated
Diphenyl
Ethers (PBDE).
Vibration:
ESL:
Weight:
Terminals:
10 Hz to 2 kHz 0.06鈥?pp max and 10 g, MIL-STD-202,
Meth. 204
<
30 nH measured 1/4鈥?from case at 1 MHz
Case EK 43 g typical
Case EA 76 g typical
Case EB 92 g typical
18 AWG copper wire with 60/40 tin-lead electroplate
CDM Cornell Dubilier
鈥?/div>
140 Technology Place
鈥?/div>
Liberty, SC 29657
鈥?/div>
Phone: (864)843-2277
鈥?/div>
Fax: (864)843-3800
