Ultrafast Recovery Diode
MPL-1036S
General Description
A surface mount device added to 600V_L series.
Realizes better space-saving in mounting on a printed circuit
board by using a surface mount package (TO-263).
January, 2006
Package
--- TO-263
Applications
鈼?/div>
Continuous-current-mode PFC circuit.
鈼?/div>
An output rectifier for SMPS, UPS, or DC-DC converters.
鈼?/div>
A Flywheel diode for inverters and choppers.
Features
鈼?/div>
Surface mount package (TO-263)
鈼?/div>
Low loss FRD (600 V_L series)
Key Specifications
Absolute maximum ratings
Parameter
Symbol
VRSM
VRM
IF(AV)
IFSM
Unit
V
V
A
A
Rating
600
600
3
50
Die Structure: Silicon Planer Diode (FRD)
Transient Peak Reverse Voltage
Peak Reverse Voltage
Average Forward Current
Peak Surge Forward Current
Electrical characteristics
Parameter
Forward Voltage Drop
Reverse Leakage Current
Reverse Leakage Current
Under High Temperature
Reverse Recovery Time
Symbol Unit
VF
IR
H鈥R
trr
V
渭A
渭A
ns
Rating
Conditions
1.75 max. IF=3A
50 max.
100 max.
50 max.
VR=VRM
VR=VRM,
Tj=150掳C
IF=IRP=100mA
90%Recovery point
Sanken Electric Co.,Ltd.
1/5
D01-007JE-060113

MPL-1036S 产品属性

  • 0现货

  • 停产

  • -

  • 散装

  • 停产

  • 标准

  • 600 V

  • 3A

  • 1.75 V @ 3 A

  • 快速恢复 =< 500ns,> 200mA(Io)

  • 50 ns

  • 50 μA @ 600 V

  • -

  • 表面贴装型

  • TO-263-3,D2Pak(2 引线 + 接片),TO-263AB

  • TO-263

  • -40°C ~ 150°C
