1.5SMCJ7.5A

更新时间:2025-04-04 00:56:04

IC热门型号推荐优势：品质保障[放心]、稳定库存[安心]、优质商家[省心] 点击搜索体验

1.5SMCJ7.5A 相关资料

1.5SMCJ7.5A的中文资料和PDF资料下载 图文及资料仅供参考，以实际PDF为准

大小：621.74KB
厂家：TAIWAN SUNMATE SEMICONDUCTOR CO.,LIMITED
描述：1.5SMCJ6.8A(CA) - 1.5SMCJ440A(CA) VOLTAGE RANGE: 6.8 - 440 V 1 of 4 POWER: 1500Wa t t s Maximum Ratings @ T A = 25C unless otherwise specified Characteristic Symbol Value Unit Peak Pulse Power Dissipation (Non repetitive current pulse derated above T A =25C) (Note 1) P PK 1500 W Peak Forward Surge Current, 8.3ms Single Half Sine Wave Superimposed on Rated Load (JEDEC Method) (Notes 1, 2, & 3) I FSM 200 A Steady State Power Dissipation @ T L = 75C PM (AV) 5.0 W Instantaneous Forward Voltage @ I PP = 100A (Notes 1 & 3) V F See Note 5 V Operating Temperature Range T j -55 to +150 C Storage Temperature Range T STG -55 to +175 C Glass Passivated Die Construction Uni- and Bi-Directional Versions Available Excellent Clamping Capability Fast Response Time Features 2. Thermal Resistance junction to Lead. NOTES:1. Non-repetitive current pulse ,per Fig. 3 and derated above TA=25℃ per Fig. 1. 3. 8.3ms single half-wave duty cycle=4 pulses per minutes
