157LMU250M2BC

更新时间:2025-04-10 03:28:52

IC热门型号推荐优势：品质保障[放心]、稳定库存[安心]、优质商家[省心] 点击搜索体验

157LMU250M2BC的中文资料和PDF资料下载 图文及资料仅供参考，以实际PDF为准

大小：507.98KB
厂家：ILLINOISCAPACITOR[Illinois Capacitor, Inc.]
描述：3757 W. Touhy Ave., Lincolnwood, Il 60712 ● (847)675-1760 ● Fax (847) 675-2850 ● www.illcap.com LMU +105°C Long Life Snap mount Aluminum Electrolytic Capacitors Features ? Standard case sizes ? Multiple case sizes ? Lead free leads ? High ripple current Applications ? Bypass ? Filtering ? Coupling ? De-coupling Specifications Operating Temperature Range -40°C to +105°C Capacitance Tolerance +20% at 120 Hz, 20°C WVDC 10 16 25 35 50 63 80 100 160 200 250 350 400 450 500 Surge voltage SVDC 13 20 32 44 63 79 100 125 200 250 300 400 450 500 550 WVDC 10 16 25 35 50 63 80 100 160 200 250 350 400 450 500 Dissipation Factor Tan δ .5 .4 .3 .25 .2 .15 .15 .15 .1 .1 .1 .15 .15 .15 .15 5 Minutes Leakage current .02CV or 2000uA,Whichever is greater WVDC 10 16 25 35 50 63 80 100 160 200 250 350 400 450 500 -25°C to +20°C 4 4 3 3 3 3 3 3 3 3 3 8 8 8 8 Low temperature stability Impedance ratio (120 Hz) -40°C to +20°C 12 12 6 6 6 6 6 6 8 8 8 - - - -
