20KP28CA

更新时间:2025-02-05 09:05:08

IC热门型号推荐优势：品质保障[放心]、稳定库存[安心]、优质商家[省心] 点击搜索体验

20KP28CA的中文资料和PDF资料下载 图文及资料仅供参考，以实际PDF为准

大小：379.09KB
厂家：SUNMATE/森美特
描述：Value POWER: 20000Wa t t s VOLTAGE RANGE: 20 - 300V AXIAL LEADED TRANSIENT VOLTAGE SUPPRESSOR DIODE 20KPA20A(CA) - 20KPA300A(CA) Case:R-6 Typical Id less than 1 A above 10V capability on 10/1000 s waveform Features @ T A = 25C unless otherwise specified Mechanical Data Maximum Ratings and Electrical Characteristics Peak Pulse Power Dissipation on 10/1000 μs Peak Pulse Current of on 10-1000 μs waveform (NOTE 1) Steady State Power Dissipation at Tl=75 °C Lead Lengths.375", (9.5mm)(NOTE 2) Peak Forward Surge Current, 8.3ms Sine-Wave Superimposed on Rated Load, (JEDEC Method) (NOTE 3) NOTES: 1.Non-repetitive current pulse, per Fig.3 and derated above Ta=25 °C per Fig.2. 2.Mounted on Copper Pad area of 0.8x0.8" (20x20mm) per Fig.5. 3.8.3ms single half sine-wave, or equivalent square wave, Duty cycle=4 pulses per minutes maximum Pm(AV) IFSM 8.0 Watts Amps 400.0 Ippm Watts Minimum 20000 Pppm SEE TABLE 1 Amps Glass passivated junction 20000W Peak Pulse Power Excellent clam
