Models 46, 47 UltraStable鈩?/div>
Medical Instrumentation
PC Board Mountable Pressure Sensor
0-100 mV Output
Gage and Absolute Pressure
Wide Temperature Range
Calibration
Process Control
Factory Automation
Air Flow Management
Leak Detection
DESCRIPTION
The Models 36 and 37 are high performance, temperature
compensated, piezoresistive silicon pressure sensors packaged in
a differential TO-8 configuration. They provide excellent
performance and long-term stability.
Differential pressure ranges from 0-15 PSI to 0-250 PSI are
available. Integral temperature compensation is provided over a
range of -20掳C to +85掳C using laser-trimmed resistors. An
additional laser-trimmed resistor is included in the Model 37 to
normalize pressure sensitivity variations by programming the
gain of an external differential amplifier. This provides
sensitivity interchangeability of 卤1%.
Please refer to the low pressure section for information on
products with operating pressures less than 0-2 PSI. For an
uncompensated sensor (Model 35) please contact the factory for
FEATURES
TO-8 Package
-20掳C to +85掳C Compensated
Temperature Range
卤0.1% Non-linearity
卤0.5% Temperature Performance
1.0% Interchangeable Span
(provided by gain set resistor)
Solid State Reliability
Low Power
additional information.
DIMENSIONS
STANDARD RANGES
Range
0 to 15
0 to 30
0 to 50
0 to 100
0 to 250
psig
psia
鈼?/div>
鈼?/div>
鈼?/div>
鈼?/div>
鈼?/div>
鈼?/div>
鈼?/div>
1-44
TO-8 鈥?Wide Temperature Range
