Made to order products,
available on request
Options : With catalogue products available to order
Motors :
- other voltages and frequencies
- lead length
- oversized winding (see page 4/4)
- for vertical operation
(see page 4/23)
- cooling fan (see page 4/24)
- coil supplied with thermal
cut-out to suit duty factor
100 掳C, 120 掳C, or 130 掳C.
- UL/CSA approved products
- rear shaft extension
24-115-240V - 50Hz
24-115V - 60Hz
Coil with flying leads (length 250 mm)
Electro-mechanical brake
(see page 4/23)
Torque /Speed curves
4
Gearboxes :
- other output speeds
- other output shafts
- output shaft carried in needle roller
bearings
- special cover (see page 4/23)
rpm
Other information
Basic principles see page 4/3
Insulation class IEC 85 : A
Speed rises by 20 % for a change in supply frequency from 50 Hz to 60 Hz.
4/14
