v3.0
eX Family FPGAs
Le a di n g E d ge P er f o r m a n ce
鈥?240 MHz System Performance
鈥?3.9ns Clock-to-Out (Pad-to-Pad)
鈥?350 MHz Internal Performance
Sp e ci f i c a t i on s
鈥?Individual Output Slew Rate Control
鈥?2.5V, 3.3V, and 5.0V Mixed Voltage Operation with 5.0V
Input Tolerance and 5.0V Drive Strength
鈥?Software Design Support with Actel Designer Series and
Libero Tools
鈥?Up to 100% Resource Utilization with 100% Pin Locking
鈥?Deterministic Timing
鈥?Unique In-System Diagnostic and Verification Capability
with Silicon Explorer II
鈥?Boundary Scan Testing in Compliance with IEEE Standard
1149.1 (JTAG)
鈥?Secure Programming Technology Prevents Reverse
Engineering and Design Theft
G en er al D e sc r i p t i on
鈥?3,000 to 12,000 Available System Gates
鈥?As Many as 512 Maximum Flip-Flops (Using CC Macros)
鈥?0.22
碌
CMOS Process Technology
鈥?Up to 132 User-Programmable I/O Pins
Fe a t ur es
鈥?High-Performance, Low-Power Antifuse FPGA
鈥?LP/Sleep Mode for Additional Power Savings
鈥?Advanced Small-footprint Packages
鈥?Hot-Swap Compliant I/Os
鈥?Single-Chip Solution
鈥?Nonvolatile
鈥?Live on power up
鈥?Power-Up/Down Friendly (No Sequencing Required for
Supply Voltages)
鈥?Configurable Weak-Resistor Pull-Up or Pull-Down for
Tristated Outputs during Power Up
eX P r o du ct Pr o f i l e
Device
Capacity
System Gates
Typical Gates
Register Cells (Dedicated Flip-Flops)
Combinatorial Cells
Maximum User I/Os
Speed Grades
Temperature Grades
Package
(by pin count)
TQFP
CSP
The eX family of FPGAs is a low-cost solution for low-power,
high-performance designs. The inherent low power
attributes of the antifuse technology, coupled with an
additional low static power mode, make these devices ideal
for power-sensitive applications. Fabricated with an
advanced 0.22
碌
CMOS antifuse technology, these devices
achieve high performance with no power penalty
.
eX64
3,000
2,000
64
128
84
鈥揊, Std, 鈥揚
C, I
64, 100
49, 128
eX128
6,000
4,000
128
256
100
鈥揊, Std, 鈥揚
C, I
64, 100
49, 128
eX256
12,000
8,000
256
512
132
鈥揊, Std, 鈥揚
C, I
100
128, 180
D e ce m b e r 2 0 0 1
1
漏 2001 Actel Corporation
