RECTRON
SEMICONDUCTOR
TECHNICAL SPECIFICATION
Z90
THRU
Z330
CURRENT- 0.5 Ampere
ZENER SILICON RETIFIER
1 WATT
VOLTAGE RANGE- 90 to 330 Volts
Absolute Maximun Ratings (Ta=25
o
C)
Items
Power Dissipation
Forward Voltage
@If = 1.0A
Vz Tolerence
Junction Temp.
Storage Temp.
Symbol
P
TOT
Vf
Ratings
1.0
1.0
20
-65 to 175
-65 to 175
Unit
W
V
%
o
C
o
C
Dimensions
DO-41
25.4 MIN
0.90
0.70
DIA
.
T
J
T
STG
Mechanical Data
Items
P a cka g e
C a se
Lead
Epoxy
Wei ght
Materi als
D O-41
Molded Plasti c
Mi l-STD -202E method 208C
guaranteed
UL94V-0 rate flame retardant
0.4 gram
5.20
4.20
2.70
2.00
DIA.
25.4 MIN
Dimensions in millimeters
Electrical Characteristics (Ta=25
o
C)
ZENER
VOLTAGE
TYPE
Vz(V)
Z90
Z100
Z105
Z110
Z115
Z120
Z130
Z135
Z140
Z150
Z160
Z170
Z180
90
100
105
110
115
120
130
135
140
150
160
170
180
@Izt(mA)
2.7
2.5
2.4
2.3
2.2
2.1
1.9
1.85
1.8
1.7
1.6
1.5
1.4
Rz (ohms)
250
350
400
450
500
550
700
750
800
1000
1100
1200
1350
@Izt(mA) Rzk (ohms) @Izk(mA)
2.7
2.5
2.4
2.3
2.2
2.1
1.9
1.85
1.8
1.7
1.6
1.5
1.4
2000
3000
3500
4000
4250
4500
5000
5250
5500
6000
6500
6750
7000
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
MAX ZENER
IMPEDANCE
MAX ZENER
IMPEDANCE
MAXIMUM
REVERSE
CURRENT
MAXIMUM
FORWARD
VOLTAGE
@VR (V)
70
75
77
80
85
90
95
100
105
110
120
130
140
IR (uA)
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
IF=1.0A
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
NOTE: Standard tolerance: +-20%, Suffix 鈥淎鈥? +-10%
