ZUP
-SERIES
Zero-up CV/CC 200 ~ 800W
Model name
ZUP 10-20
Series
Output
voltage
(0 ~ 10V)
Output
current
(0 ~ 20A)
Features
Programmable power supply
Constant voltage/Constant current
Built-in RS232 & RS485 interface
GP-IB interface: Option
External voltage or resistor programming
Last setting memory with safe restart or automatic restart
modes
Input current harmonics: EN61000-3-2 Class A
(Low Voltage Directive)
Specifications
Input
1. Input voltage range
2. Input current
harmonics
3. Power factor (typ)
Output
1. Constant voltage
85 ~ 265VAC (47 ~ 63Hz) universal input voltage
Complies with EN61000-3-2 Class A.
0.99 at 100VAC, 100% load
Load Regulation: 0.005% +2mV, Line Regulation: 0.005% +1mV
RMS ripple: 5mV (5Hz ~ 1MHz bandwidth)
Ripple :50mV(pk to pk) (20MHz bandwidth)
Load Regulation: 0.01% +5mA, Line Regulation: 0.01% +2mA
Over voltage, Over temperature, Over current
0 ~ +50掳C: 100% load
By TTL signal or Dry contact
By voltage (0 ~ 4V) or by Resistance (0 ~ 4k鈩?
By voltage (0 ~ 4V) or by Resistance (0 ~ 4k鈩?
Maximum 0.5V drop on each load wires
RS232 and RS485 built-in, IEEE488 option
2. Constant current
3. Output protections
Environment
1. Operating temperature
External functions
1. Output ON/OFF
2. Output voltage
programming
3. Output current
programming
4. Remote sensing
5. Communication
interface
Approval
1. Safety standard
2. EMC standard
System Power Supply
UL3111-1, EN61010-1
EN61326-1, IEC61326-1 FCC part 15 class A
Product lineup
Model name
ZUP6-33
ZUP6
ZUP6-66
ZUP6-132 (*)
ZUP10-20
ZUP10
ZUP10-40
ZUP10-80 (*)
ZUP20-10
ZUP20
ZUP20-20
ZUP20-40 (*)
ZUP36-6
ZUP36
ZUP36-12
ZUP36-24 (*)
ZUP60-3.5
ZUP60
ZUP60-7
ZUP60-14 (*)
ZUP80
ZUP120
ZUP80-2.5
ZUP80-5
ZUP120-1.8
ZUP120-3.6
0 ~ 80VDC
0 ~ 120VDC
0 ~ 60VDC
0 ~ 36VDC
0 ~ 20VDC
0 ~ 10VDC
0 ~ 6VDC
Output voltage
Output current
0 ~ 33A
0 ~ 66A
0 ~ 132A
0 ~ 20A
0 ~ 40A
0 ~ 80A
0 ~ 10A
0 ~ 20A
0 ~ 40A
0 ~ 6A
0 ~ 12A
0 ~ 24A
0 ~ 3.5A
0 ~ 7A
0 ~ 14A
0 ~ 2.5A
0 ~ 5A
0 ~ 1.8A
0 ~ 3.6A
Output power
198W
396W
792W
200W
400W
800W
200W
400W
800W
216W
432W
864W
210W
420W
840W
200W
400W
216W
432W
Weight
2.9kg
3.2kg
5.8kg
2.9kg
3.2kg
5.8kg
2.9kg
3.2kg
5.8kg
2.9kg
3.2kg
5.8kg
2.9kg
3.2kg
5.8kg
2.9kg
3.2kg
2.9kg
3.2kg
193
(*) Contact us about delivery before ordering.
