Cyclone FPGA Family Data Sheet
Preliminary Information
Figure 39. Cyclone Device Packaging Ordering Information
EP1C
Family Signature
EP1C: Cyclone
20
F
400
C
7
ES
Optional Suffix
Indicates specific device options or
shipment method.
ES: Engineering sample
Device Type
3
4
6
12
20
Speed Grade
6, 7, or 8 , with 6 being the fastest
Operating Temperature
Package Type
T: Thin quad flat pack (TQFP)
Q: Plastic quad flat pack (PQFP)
F: FineLine BGA
Pin Count
Number of pins for a particular package
C: Commercial temperature (t
J
= 0
藲
C to 85
藲
C)
I: Industrial temperature (t
J
= -40
藲
C to 100
藲
C)
Revision
History
The information contained in the
Cyclone FPGA Family Data Sheet
version 1.1 supersedes information published in previous versions. The
following changes were made to the
Cyclone FPGA Family Data Sheet
version 1.1:
鈻?/div>
鈻?/div>
鈻?/div>
Added the EP1C4 device.
Updated the
鈥淭iming Model鈥?/div>
section.
Minor textual updates throughout the document.
庐
101 Innovation Drive
San Jose, CA 95134
(408) 544-7000
http://www.altera.com
Applications Hotline:
(800) 800-EPLD
Customer Marketing:
(408) 544-7104
Literature Services:
lit_req@altera.com
94
Copyright 漏 2003 Altera Corporation. All rights reserved. Altera, The Programmable Solutions Company, the
stylized Altera logo, specific device designations, and all other words and logos that are identified as
trademarks and/or service marks are, unless noted otherwise, the trademarks and service marks of Altera
Corporation in the U.S. and other countries. All other product or service names are the property of their
respective holders. Altera products are protected under numerous U.S. and foreign patents and pending
applications, maskwork rights, and copyrights. Altera warrants performance of its semiconductor products to
current specifications in accordance with Altera鈥檚 standard warranty, but reserves the
right to make changes to any products and services at any time without notice. Altera
assumes no responsibility or liability arising out of the application or use of any
information, product, or service described herein except as expressly agreed to in writing
by Altera Corporation. Altera customers are advised to obtain the latest version of device
specifications before relying on any published information and before placing orders for
products or services.
Altera Corporation

EP1C12F256I7N 产品属性

  • Three Reasons to Use FPGA's in Industrial Designs

  • 90

  • 集成电路 (IC)

  • 嵌入式 - FPGA（现场可编程门阵列）

  • Cyclone®

  • 1206

  • 12060

  • 239616

  • 185

  • -

  • 1.425 V ~ 1.575 V

  • 表面贴装

  • -40°C ~ 100°C

  • 256-BGA

  • 256-FBGA（17x17）

  • 544-1676
