For stabilized power supply.
鈥?/div>
Diffused-junction. Glass passivated and
encapsulated.
OUTLINE DRAWING
蠁
3.5 MAX
(0.14)
Unit in mm(inch)
Cathode band (Red)
Type mark (Red)
29MIN.
(1.14)
62MIN. (2.44)
5MAX
(0.2)
29MIN.
(1.14)
蠁
0.8
(0.03)
Direction of polarity
06NA
Weight: 0.35 (g)
ABSOLUTE MAXIMUM RATINGS
Items
Permissible Power Dissipation
Operating Junction Temperature
Storage Temperature
Maximum Permissible Current
Non-Repetitive Peak Reverse One-
Cycle Dissipation
Symbols
P
T
j
T
stg
I
ZM
P
RSM
Units
W
掳C
掳C
mA
Wp
Ratings
1.0
-40 ~ +150
-40 ~ +150
Refer to characteristics column
80
Notes
(1) Lead mounting : Lead temperature 300掳C max. to 3.2mm from body for 5sec. max..
(2) Mechanical strength : Bending 90掳脳2 cycles or 180掳脳1 cycle, Tensile 2kg, Twist 90掳脳1 cycle.
CHARACTERISTICS(T
L
=25掳C)
Type
Characteristics
Zener Voltage Vz (V)
Maximum
Dynamic
Impedance
Minimum
Maximum
Zz (ohm)
5.2
6.2
7.7
8.5
9.4
10.4
11.4
12.4
13.5
15.3
16.8
18.8
20.8
22.7
25.1
28.0
31.0
6.8
7.9
8.7
9.6
10.6
11.6
12.7
14.1
15.6
17.1
19.1
21.2
23.3
25.6
28.9
32.0
35.0
9
7
3
3
5
5
8
8
12
12
15
15
15
15
15
15
15
Test Current
Iz
(mA)
60
25
25
25
25
25
25
25
15
15
15
15
15
10
10
10
10
Maximum
Permissible
Current
(TL=100掳C)
(L=10mm)
I
ZM
(mA)
160
135
120
105
95
85
75
70
65
60
52
48
43
40
35
32
30
AW01-06
AW01-07
AW01-08
AW01-09
AW01-10
AW01-11
AW01-12
AW01-13
AW01-15
AW01-16
AW01-18
AW01-20
AW01-22
AW01-24
AW01-27
AW01-30
AW01-33
Typical
Zener
Voltage
Temperature
Coefficient
纬
z(%/掳C)
0.025
0.035
0.045
0.053
0.058
0.063
0.065
0.068
0.072
0.074
0.076
0.078
0.080
0.081
0.082
0.083
0.084
PDE-AW01-0
1
2
3
4
