1.0 Pitch 2.54
The module includes the Vacuum Fluorescent Display
glass, driver and micro-controller ICs with refresh RAM,
character generator and interface logic.
The high speed 8 bit parallel interface is 5V CMOS
compatible suitable for connection to a host CPU bus
which can be set to M68 or i80 series interface by a solder
link on the module. Brightness control and power save
functions are provided. Please call for a full data sheet.
11.5 26.5 33.5
1
11.0
17.6
138.8
175.0
182.0
3.5
3.5
1.6
12.0 max
8.5 max
ELECTRICAL SPECIFICATION
Parameter
Symbol
Power Supply Voltage
V
CC
Power Supply Current
I
CC
Logic High Input (DB0-DB7)
V
IH1
Logic Low Input (DB0-DB7)
V
IL1
Logic High Input (RS,R/W,E) V
IH2
Logic Low Input (RS,R/W,E)
V
IL2
Logic High Output
V
OH
Logic Low Output
V
OL
Dimensions in mm & subject to tolerances. Mounting holes 3.5mm dia.
CHARACTER FONT
Value
5.0VDC +/- 5%
330mADC typ.
Vss+2.2VDC min.
Vss+0.6VDC max
0.7 V
CC
min.
0.3 V
CC
max.
Vcc-0.5VDC min.
Vss+0.4VDC max
Condition
G
ND
=0V
Vcc=5V
V
CC
=5V
V
CC
=5V
V
CC
=5V
V
CC
=5V
I
OH
= -1.6mA
I
OL
=1.6mA
The power on rise time should be less than 50ms.The inrush current at power on can be 2 x I
CC
.
The Icc current is 10mA maximum while in power save mode.
OPTICAL and ENVIRONMENTAL SPECIFICATIONS
Parameter
Value
Character Size/Pitch (XxY mm)
2.3 x 4.7/3.5 x 6.1
Dot Size/Pitch (XxY mm)
0.38 x 0.5/0.48 x 0.7
Luminance
700 cd/m
2
(204 fL) Typ.
Colour of Illumination
Blue-Green
(Filter for more colours)
Operating Temperature
-40掳C to +85掳C
Storage Temperature
-50掳C to +85掳C
Operating Humidity (non condensing) 20 to 80% RH @ 25掳C
SOFTWARE COMMANDS
Instruction
R/W
Clear Display
L
Cursor Return Home
L
Entry Mode Set
L
Display ON/OFF
L
Cursor/Display Shift
L
Function Set
L
Brightness Set
L
Set CG RAM Addr.
L
Set DD RAM Addr.
L
Read BUSY/Addr.
H
Write Data to RAM
L
Read Data from RAM H
RS
L
L
L
L
L
L
H
L
L
L
H
H
D0-D7
01H
02H-03H
04H-07H
08H-0FH
10H-1FH
20H-3FH
00H-03H
40H-7FH
80H-E7H
00H-FFH
00H-FFH
00H-FFH
PIN CONNECTIONS
Pin
Sig
Pin
1
G
ND
2
3
(F
NC
) 4
5
R/W # 6
7
D0
8
9
D2
10
11
D4
12
13
D6
14
Sig
V
CC
RS
E#
D1
D3
D5
D7
JUMPER LINKS
#
Interface M68/i80
When jumper link JP2 is
soldered, these inputs
change to i80 series CPU
control lines.
Pin 5= /WR Pin 6 = /RD
CONTACT
TIMING PARAMETERS
(min
)
(E) nable Cycle Time
666ns
(E) nable Pulse Width 300ns
Hold after (E) nable
10ns
Noritake Sales Office Tel Nos
Nagoya Japan: +81 (0)52-561-9867
Canada: +1-416-291-2946
Chicago USA: +1-847-439-9020
Munchen (D): +49 (0)89-3214-290
Itron UK: +44 (0)1493 601144
Rest Europe: +49 (0)61-0520-9220
Pin 3 (Fnc) Input
www.noritake-itron.com
This is normally open circuit.
Subject to change without notice.
If pads JP4.1 and JP4.2 are
IUK Doc Ref: 03445 Iss:1 11 July 2001
linked. Pin 3 = /Reset.
NORITAKE ITRON VFD MODULES
2x40, 5mm Dot Character
