EXTENDED TEMPERATURE
SURFACE MOUNT 10BASE-T
INTERFACE MODULES
Fully Integrated for Adapter, Hub,
and Motherboard Applications
!
UCT
D
PRO
NEW
Extended temperature operates
from -40掳C to +85掳C
Meets IEEE 802.3 specification
EX2001 part is designed for AMD
extended temperature transceiver
235掳C peak infrared reflow
temperature rating
Electrical Specifications @ 25掳C 鈥?Operating Temperature -40掳C to +85掳C
Part
Number
Insertion
Loss
1 to 10 MHz
(dB MAX)
-1.0
Attenuation
(XMIT)
(dB MIN)
30 MHz
-30
50 MHz
-35
100 MHz
-35
Return Loss
5 to 10MHz
(dB MIN)
100
鈩?/div>
-18
98 卤13
鈩?/div>
-15
Crosstalk
(dB MIN)
5-10 MHz
-35
Common Mode Rejection
(XMIT)
(db MIN)
5 MHz 10 MHz 50 MHz 100 MHz 200MHz
-60
-60
-55
-50
-45
Hi-Pot
(V
RMS
MIN)
EX2001
1800
NOTE:
Turns ratios are 1:1 for the EX2001. The receive and transmit sides meet IEEE 802.3i specifications. Specifications reflect filter sections.
Mechanical
EX2001
.930
MAX
23,62
.405
10,29
.510
MAX
12,95
DATE CODE
COUNTRY OF ORIGIN
.530
13,46
EX2001
.100
2,54
7X
7X .100
2,54
.700
17,78
.100 (=.700)
2,54 (=17,78)
16X .040
1,02
SUGGESTED PAD LAYOUT
.390
MAX
9,91
.004/ 0,100
16 SURFACES
.040
1,02
16X .018
0,46
0掳 鈥?8掳
16X .035
0,89
.230
MAX
5,84
Weight
. . . . . . . . . . . . . . .2.5 grams
Tape & Reel
. . . . . . . . . . . .250/reel
Tube
. . . . . . . . . . . . . . . . . .20/tube
Dimensions:
Inches
mm
Unless otherwise specified, all tolerances are 卤 .010
0,25
U.S.A:
TEL 619 674 8100
鈥?/div>
EUROPE:
TEL 44 1483 401700
鈥?/div>
ASIA:
TEL 65 287 8998
鈥?/div>
WEB:
http://www.pulseeng.com
1
E112.P (3/99)
