JDV2S05E
TOSHIBA Diode Silicon Epitaxial Planar Type
JDV2S05E
VCO for UHF band
鈥?/div>
鈥?/div>
鈥?/div>
Small Package
High Capacitance Ratio : C
1V
/C
4V
=
1.9 (typ.)
Low Series Resistance : r
s
=
0.30
鈩?/div>
(typ.)
Maximum Ratings
(Ta
=
25掳C)
Characteristics
Reverse voltage
Junction temperature
Storage temperature range
Symbol
V
R
T
j
T
stg
Rating
10
125
鈭?5~125
Unit
V
掳C
掳C
Weight: 0.0014 g
000707EAA1
鈥?/div>
TOSHIBA is continually working to improve the quality and reliability of its products. Nevertheless, semiconductor devices in general
can malfunction or fail due to their inherent electrical sensitivity and vulnerability to physical stress. It is the responsibility of the
buyer, when utilizing TOSHIBA products, to comply with the standards of safety in making a safe design for the entire system, and
to avoid situations in which a malfunction or failure of such TOSHIBA products could cause loss of human life, bodily injury or
damage to property.
In developing your designs, please ensure that TOSHIBA products are used within specified operating ranges as set forth in the
most recent TOSHIBA products specifications. Also, please keep in mind the precautions and conditions set forth in the 鈥淗andling
Guide for Semiconductor Devices,鈥?or 鈥淭OSHIBA Semiconductor Reliability Handbook鈥?etc..
鈥?/div>
The TOSHIBA products listed in this document are intended for usage in general electronics applications (computer, personal
equipment, office equipment, measuring equipment, industrial robotics, domestic appliances, etc.). These TOSHIBA products are
neither intended nor warranted for usage in equipment that requires extraordinarily high quality and/or reliability or a malfunction or
failure of which may cause loss of human life or bodily injury (鈥淯nintended Usage鈥?. Unintended Usage include atomic energy
control instruments, airplane or spaceship instruments, transportation instruments, traffic signal instruments, combustion control
instruments, medical instruments, all types of safety devices, etc.. Unintended Usage of TOSHIBA products listed in this document
shall be made at the customer鈥檚 own risk.
鈥?/div>
The information contained herein is presented only as a guide for the applications of our products. No responsibility is assumed by
TOSHIBA CORPORATION for any infringements of intellectual property or other rights of the third parties which may result from its
use. No license is granted by implication or otherwise under any intellectual property or other rights of TOSHIBA CORPORATION or
others.
鈥?/div>
The information contained herein is subject to change without notice.
2000-09-11
1/3
