LMV841 CMOS Input, RRIO, Wide Supply Range Operational Amplifier
December 2006
LMV841
CMOS Input, RRIO, Wide Supply Range Operational
Amplifier
General Description
The LMV841 is a low-voltage and low-power operational am-
plifier that operates from supply voltages from 2.7V to 12V
and has rail-to-rail input and output capability.
The LMV841 is a low offset voltage and low supply current
amplifier with MOS inputs, characteristics that make the
LMV841 ideal for sensor interface and battery powered ap-
plications.
The LMV841 is offered in the space saving 5-Pin SC70 pack-
age. This small package is an ideal solution for area con-
strained PC boards and portable electronics.
Features
Unless otherwise noted, typical values at T
A
= 25掳C, V
+
= 5V
鈻?/div>
Space saving 5-Pin SC70 package
鈻?/div>
Supply voltage range 2.7V to 12V
鈻?/div>
Guaranteed at 3.3V, 5V and 卤5V
1 mA
鈻?/div>
Low supply current
4.5 MHz
鈻?/div>
Unity gain bandwidth
100 dB
鈻?/div>
Open loop gain
500 渭V
max
鈻?/div>
Input offset voltage
Input bias current
0.3 pA
鈻?/div>
100 dB
鈻?/div>
CMRR
20 nV/
鈻?/div>
Input voltage noise
鈥?0掳C to 125掳C
鈻?/div>
Temperature range
鈻?/div>
Rail-to-rail input
鈻?/div>
Rail-to-rail output
Applications
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
High impedance sensor interface
Battery powered instrumentation
High gain amplifiers
DAC buffer
Instrumentation amplifiers
Active Filters
Typical Application
Active Band-pass Filter
20168372
漏 2006 National Semiconductor Corporation
201683
www.national.com
