MAX2242 Evaluation Kit
General Description
The MAX2242 evaluation kit (EV kit) simplifies evalua-
tion of the MAX2242 power amplifier (PA), which is
designed for 2.4GHz ISM-band direct-sequence
spread-spectrum (DSSS) applications. The kit enables
testing of the device鈥檚 RF performance and requires no
additional support circuitry. The EV kit input and output
use SMA connectors to facilitate the connection to RF
test equipment.
Each kit is assembled with the MAX2242 and incorpo-
rates input- and output-matching components opti-
mized for the 2.4GHz to 2.5GHz RF frequency band.
o
Easy Evaluation of MAX2242
o
+2.7V to +3.6V True Single-Supply Operation
o
Output Matched for 2.4GHz to 2.5GHz Operation
o
All Matching Components Included
Features
Evaluates: MAX2242
Ordering Information
PART
MAX2242EVKIT
TEMP. RANGE
-40掳C to +85掳C
IC-PACKAGE
3
脳
4 UCSP
MAX2242 EV Kit Component List
DESIGNATION
QTY
DESCRIPTION
33pF 5% 50V ceramic
capacitors (0402), Murata
GRM36C0G330J050AD or Taiyo
Yuden UMK105CH330JW
1.8pF
卤0.1pF
50V ceramic
capacitor (0402), Murata
GRM36C0G1R8B050AD or
Taiyo Yuden EVK105CH1R8JW
0.1碌F 10% 10V ceramic
capacitors (0402)
Murata GRM36X5R104K010 or
Taiyo Yuden LMK105BJ104MV
Not installed
22碌F 16V tantalum capacitor
(Case B)
AVX TAJB226M016
6.0pF
卤0.1pF
50V ceramic
capacitor (0402), Murata
GRM36C0G060B050AD or
Taiyo Yuden EVK105CH060JW
10nH
卤0.3nH
5% inductor
(0402)
Coilcraft 0402CS-10NXJBG
2.2nH inductor (0402)
Murata LQP10A2N2B00
DESIGNATION
R1, R2
R3
R4
QTY
2
1
1
DESCRIPTION
8.06k鈩?/div>
卤1%
resistors (0402)
47k鈩?/div>
卤5%
resistor (0402)
51鈩?/div>
卤5%
resistor (0402)
SMA connectors (PC edge-
mount)
EFJohnson 142-0701-801 or
Digi-Key J502-ND
3-pin header
Digi-Key S1012-36-ND or
equivalent
1-pin headers
Digi-Key S1012-36-ND or
equivalent
Shunt for JU1
Digi-Key S9000-ND or
equivalent
Test points
Mouser 151-203
MAX2242EBC (3脳4 UCSP)
MAX2242 PC board
MAX2242 data sheet
MAX2242 EV kit data sheet
C1, C9
2
C2
IN, OUT
2
1
JU1
1
C3, C6, C8,
C10
C4, C7
C5
4
BIAS, PDOUT
2
2
1
None
1
VCC, GND
U1
None
None
None
2
1
1
1
1
C12
1
L1
1
L2
1
