MIC923
Micrel
MIC923
410MHz Low-Power SC70 Op Amp
Final Information
General Description
The MIC923 is a high-speed operational amplifier with a gain-
bandwidth product of 410MHz. The part is unity gain stable.
It has a very low 2.5mA supply current, and features the
Teeny鈩C70
package.
Supply voltage range is from
卤2.5V
to
卤9V,
allowing the
MIC923 to be used in low-voltage circuits or applications
requiring large dynamic range.
The MIC923 requires a minimum gain of +2 or 鈥? but is stable
driving any capacitive load. It has excellent PSRR and
CMRR, making it much easier to use than most conventional
high-speed devices. Low supply voltage, low power con-
sumption, and small packaging make the MIC923 ideal for
portable equipment. The ability to drive capacitative loads
also makes it possible to drive long coaxial cables.
Features
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
410MHz gain bandwidth product
2.5mA supply current
Teeny鈩?/div>
SC70 packaging
2200V/碌s slew rate
Drives any capacitive load
Stable with gain
鈮?
or 鈥?
Video
Imaging
Ultrasound
Portable equipment
Line drivers
Applications
Ordering Information
Part Number
MIC923BC5
Junction Temp. Range
鈥?0掳C to +85掳C
Package
SC-70
Pin Configuration
IN鈥?/div>
3
Functional Pinout
V鈥?/div>
2
IN+
1
IN鈥?/div>
V鈥?/div>
2
IN+
1
Part
Identification
3
A40
4
5
4
5
OUT
V+
OUT
V+
SC-70
SC-70
Pin Description
Pin Number
1
2
3
4
5
Pin Name
IN+
V鈥?/div>
IN鈥?/div>
OUT
V+
Pin Function
Noninverting Input
Negative Supply (Input)
Inverting Input
Output: Amplifier Output
Positive Supply (Input)
Micrel, Inc. 鈥?1849 Fortune Drive 鈥?San Jose, CA 95131 鈥?USA 鈥?tel + 1 (408) 944-0800 鈥?fax + 1 (408) 944-0970 鈥?http://www.micrel.com
March 2002
1
