Quartz SMD
MP6914
Features:
- Surface mount
- High performance/cost ratio
- Excellent vibration & shock resistance
Specifications
Frequency range
Frequency tolerance,Ta=25掳C
Load capacitance
Temp.coefficient
Temperature range
Storage temp.
Operating temp.
Drive level
Maximum drive level
Recommended drive level
Series resistance
Shunt capacitance
Insulation resistance
Aging
Shock resistance
Symbol
f
Df/f
C
L
A
T
STG
T
OPR
M
DL
R
DL
R
1
C
0
I
R
Df
A
SR
MP6914
32.768kHz
卤 20ppm ~ 卤 50ppm (std.)
7pF ~ 12.5pF (std.)
-0.04 x 10-6 / 掳C虏
-55掳C ~ +125掳C
-10掳C ~ +60掳C
1mW
-
70k Ohm
1.3pF ~ 2pF
500M Ohm
卤 5ppm/Year typ
卤 10ppm
Remarks
Standard
Others are offered
Please specify
Max
Others are offered
Standard
Max (25掳C)
Min
卤 5ppm/Year max
Max
Drawing
MP6914
Dimensions in mm
Order key
Q
Part
- 32.768000k - MP6914 - 50
Frequency
Package
Frequency
tolerance
-B
Temperature
range
A=
0掳C ~ 70掳C
- 12.5
Load
capacitance
pF
SR=series
- TR
Option
Q=Quartz
k=kHz
MP6914
+/-ppm
(25掳C)
TR=Tape and reel
X=Special options
B=-10掳C ~ 60掳C
C=-10掳C ~ 70掳C
D=-20掳C ~ 70掳C
E=-40掳C ~ 85掳C
Remarks: All specifications subject to change without notice!
