PI3L100
3.3V, Wide Bandwidth Quad 2:1
Mux/Demux LanSwitch
Features
鈥?Replaces mechanical relays
鈥?High-performance, low-cost solution for switching
between different LAN signals
鈥?Ultra-low quiescent power (0.1碌A typical)
鈥?Low crosstalk: 鈥?0dB @ 30 MHz
鈥?Low insertion loss or on-resistance: 3鈩?typical
鈥?Single supply operation: 3.3V
鈥?Off isolation: 鈥?5dB @ 30 MHz
鈥?Wide bandwidth data rates > 200 MHz
鈥?Packages available:
鈥?16-pin 150 mil wide plastic QSOP (Q)
鈥?16-pin 173 mil wide plastic TSSOP (L)
Description
Pericom Semiconductor鈥檚 PI3L series of logic circuits are produced
using the Company鈥檚 advanced submicron CMOS technology.
The PI3L100 is a Quad 2:1 multiplexer/demultiplexer LanSwitch
with three-state outputs. This device can be used for switching
between various standards, such as 10 Base-T and 100 Base-T.
Generally, this part can be used to replace mechanical relays in low
voltage LAN applications that have physical layer, unshielded
twisted pair media (UTP) with either CAT 3 or CAT 5 grade cable.
Logic Block Diagram
IA
0
IA
1
IB
0
IB
1
IC
0
IC
1
ID
0
ID
1
16-Pin Product Configuration
S
IA0
IA1
YA
IB0
IB1
YB
GND
1
2
3
4
5
6
7
8
16
15
14
16-Pin
W,L
13
12
11
10
9
V
CC
E
ID0
ID1
YD
IC0
IC1
YC
E
Product Pin Description
S
YA
YB
YC
YD
Pin Name
IAn-IDn
S
E
YA-YD
GND
V
CC
Description
Data Inputs
Select Inputs
Enable
Data Outputs
Ground
Power
Truth Table
(1)
E
H
L
L
S
X
L
H
YA
Hi-Z
IA0
IA1
YB
Hi-Z
IB0
IB1
YC
Hi-Z
IC0
IC1
YD
Hi-Z
ID0
ID1
Function
Disable
S=0
S=1
Note:
1. H = High Voltage Level
L = Low Voltage Level
1
PS8504
11/13/00
1
2
3
4
5
6
