STU606I - STU65G4
V
BR
: 6.8 - 440 Volts
P
PK
: 600 Watts
FEATURES :
* 600W surge capability at 1ms
* Excellent clamping capability
* Low zener impedance
* Fast response time : typically less
then 1.0 ps from 0 volt to V
BR(min.)
* Typical I
R
less then 1
碌
A above 10V
SURFACE MOUNT TRANSIENT
VOLTAGE SUPPRESSOR
SMB (DO-214AA)
1.1
卤
0.3
5.4
卤
0.15
4.8
卤
0.15
2.0
卤
0.1
3.6
卤
0.15
2.3
卤
0.2
0.22
卤
0.07
MECHANICAL DATA
* Case : SMB Molded plastic
* Epoxy : UL94V-O rate flame retardant
* Lead : Lead Formed for Surface Mount
* Polarity : Color band denotes cathode end except Bipolar.
* Mounting position : Any
* Weight : 0.093 grams
Dimensions in millimeter
DEVICES FOR BIPOLAR APPLICATIONS
For bi-directional altered the third letter of type from "U" to be "B".
Electrical characteristics apply in both directions
MAXIMUM RATINGS
Rating at 25
掳
C ambient temperature unless otherwise specified.
Rating
Peak Power Dissipation at Ta = 25
掳
C, Tp=1ms
(Note1)
Steady State Power Dissipation at T
L
= 75
掳
C
Peak Forward Surge Current, 8.3ms Single Half
Sine-Wave Superimposed on Rated Load
(JEDEC Method)
(Note 3)
Symbol
P
PK
P
D
Value
Minimum 600
5.0
Unit
Watts
Watts
I
FSM
T
J,
T
STG
100
- 55 to + 150
Amps.
掳
C
Operating and Storage Temperature Range
Note :
(1) Non-repetitive Current pulse, per Fig. 5 and derated above Ta = 25
掳
C per Fig. 1
2
(2) Mounted on copper Lead area at 5.0 mm ( 0.013 mm thick ).
(3) 8.3 ms single half sine-wave, duty cycle = 4 pulses per Minutes maximum.
