Ordering number:ENN5527A
Silicon Diffused Junction Type Varactor Diode
SVC231
FM Receiver Electronic Tuning Applications
Features
路 Twin type varactor diode having an excellent large
input characteristic and intended for use in low-
voltage (high-voltage) FM electronic tuning applica-
tions.
路 Small-sized package (CP), permitting SVC231-
applied sets to be compact and slim.
路 Possible to offer the SVC231 devices in a tape reel
packaging, which facilitates automatic insertion.
路 High Q.
Electrical Connection
Cathode
0.8
1.1
Package Dimensions
unit:mm
1169A
[SVC231]
0.5
0.4
3
0.16
0 to 0.1
1
0.95 0.95
2
1.9
2.9
0.5
1.5
2.5
1 : Anode
2 : Anode
3 : Cathode
SANYO : CP
Anode
Anode
Specifications
Absolute Maximum Ratings
at Ta = 25藲C
Parameter
Reverse Voltage
Junction Temperature
Storage Temperature
Symbol
VR
Tj
Tstg
Conditions
Ratings
16
125
鈥?5 to +125
Unit
V
藲C
藲C
Electrical Characteristics
at Ta = 25藲C
Parameter
Breakdown Voltage
Reverse Current
Interterminal Capacitance *
Quality Factor
Capacitance Ratio
Matching Tolerance
Symbol
V(BR)R
IR
C2V
C8V
Q
CR
鈭?/div>
Cm
IR=10碌A
VR=10V
VR=2.0V, f=1MHz
VR=8.0V, f=1MHz
VR=3.0V, f=100MHz
C2.0V/C8.0V
VR=2.0V, 8.0V, f=1MHz, (Cmax-Cmin) / Cmin
脳
100
43.89
17.65
100
2.3
2.6
3
%
Conditions
Ratings
min
16
50
51.02
21.50
typ
max
Unit
V
nA
pF
pF
Note )* : Capacitance value of one diode
Marking : RV
Any and all SANYO products described or contained herein do not have specifications that can handle
applications that require extremely high levels of reliability, such as life-support systems, aircraft鈥檚
control systems, or other applications whose failure can be reasonably expected to result in serious
physical and/or material damage. Consult with your SANYO representative nearest you before using
any SANYO products described or contained herein in such applications.
SANYO assumes no responsibility for equipment failures that result from using products at values that
exceed, even momentarily, rated values (such as maximum ratings, operating condition ranges,or other
parameters) listed in products specifications of any and all SANYO products described or contained
herein.
SANYO Electric Co.,Ltd. Semiconductor Company
TOKYO OFFICE Tokyo Bldg., 1-10, 1 Chome, Ueno, Taito-ku, TOKYO, 110-8534 JAPAN
O0899GI (KT) No.5527鈥?/4
