T15V2M16B

SRAM

FEATURES

鈥?/div>

Access time : 45/55/70/100 ns

鈥?/div>

Low-power consumption

- Active: 5mA (I

CC1

)

- Stand-by: (CMOS input/output)

Max.. 15 uA for 55/70/100ns

Max.. 40 uA for 45ns

鈥?/div>

Equal access and cycle time

鈥?/div>

Single +2.7V to 3.6V Power Supply

鈥?/div>

TTL compatible , Tri-state output

鈥?/div>

Common I/O capability

鈥?/div>

Automatic power-down when deselected

鈥?/div>

Available in 44-PIN TSOP-II and 48-pin CSP

packages

鈥?/div>

Operating temperature :

-10 ~ +70

掳C

-40 ~ +85

掳C

128K X 16 LOW POWER

CMOS STATIC RAM

GENERAL DESCRIPTION

The T15V2M16B is a very Low Power CMOS

Static RAM organized as 131,072 words by 16

bits

This

device

fabricated by high

performance CMOS technology. It can be operated

under wide power supply voltage range from

+2.7V to +3.6V.

The T15V2M16B inputs and three-state

outputs are TTL compatible and allow for direct

interfacing with common system bus structures.

Data retention is guaranteed at a power supply

voltage as low as 2V.

BLOCK DIAGRAM

PART NUMBER EXAMPLES

PART NUMBER

T15V2M16B-55S

T15V2M16B-70C

T15V2M16B-55SI

T15V2M16B-70CI

PACKAGE

TSOP-II

CSP

TSOP-II

CSP

Temperature

-10 ~ +70

掳C

-10 ~ +70

掳C

-40 ~ +85

掳C

-40 ~ +85

掳C

Vcc

Vss

DECODER

CORE

ARRAY

A16

CONTROL

CIRCUIT

DATA I/O

I/O1

I/O16

TM Technology Inc. reserves the right

to change products or specifications without notice.

P. 1

Publication Date: NOV. 2002

Revision:A
