ZLLS2000
40V SILICON HIGH CURRENT LOW LEAKAGE SCHOTTKY DIODE
SUMMARY
Schottky Diode V
R
= 40V; I
F
= 2.2A; I
R
= 40 A
DESCRIPTION
This compact SOT23-6 packaged Schottky diode offers users an excellent
performance combination comprising high current operation, extremely low leakage
and low forward voltage ensuring suitability for applications requiring efficient
operation at higher temperatures ( above 85 C) see Operational Efficiency chart on
page 4.
Key benefits:
Performance capability equivalent to much larger packages
Improved circuit efficiency & power levels
PCB area savings
FEATURES
路
Low Equivalent On Resistance
路
Extremely Low Leakage (40 A @30V)
路
High current capability (I
F
= 2.2A)
路
Low V
F
, Fast switching Schottky
路
SOT23-6 Package
路
ZLLS2000 complements low temperature equivalent ZHCS2000
路
Package thermally rated to 150 C
APPLICATIONS
路
DC - DC Converters
路
Strobes
路
Mobile Phones
路
Charging Circuits
路
Motor control
ORDERING INFORMATION
DEVICE
REEL
TAPE WIDTH
(inches) (mm)
8mm embossed
8mm embossed
QUANTITY
PER REEL
3000 units
10000 units
ZLLS1000TA 7
ZLLS1000TC
13
Top view
DEVICE MARKING
L10
ISSUE 1 - JANUARY 2002
