CS5342

105 dB, 192 kHz, Multi-bit Audio A/D Converter

Features

Advanced Multi-bit Delta-Sigma Architecture

24-bit Conversion

Supports all audio sample rates including

192 kHz.

105 dB Dynamic Range at 5 V

-98 dB THD+N

High-pass Filter to Remove DC Offsets

Analog/Digital Core Supplies From 3.3 V to 5 V

Supports logic levels between 2.5 V and 5 V.

Low-latency Digital Filter

Automatic Mode Selection

Supports 384x MCLK/LRCK Ratios.

General Description

The CS5342 is a complete analog-to-digital converter for

digital audio systems. It performs sampling, analog-to-

digital conversion and anti-alias filtering, generating

24-bit values for both left and right inputs in serial form at

sample rates up to 200 kHz per channel.

The CS5342 uses a 5th-order, multi-bit Delta-Sigma

modulator followed by digital filtering and decimation,

which removes the need for an external anti-alias filter.

The CS5342 is ideal for audio systems requiring wide dy-

namic range, negligible distortion and low noise, such as

set-top boxes, DVD-karaoke players, DVD recorders,

A/V receivers, and automotive applications.

ORDERING INFORMATION

CS5342-CZZ Lead-free

CS5342-DZZ Lead-free

CDB5342

-10掳 to 70掳 C

-40掳 to 85掳 C

16-pin TSSOP

16-pin TSSOP

Evaluation Board

VQ

REFGND

V

L

2.5V - 5.0V SCLK LRCK SDOUT

MCLK

FILT+

Voltage Reference

Serial Output Interface

RST

M0

M1

AINL

S/H

+

-

LP Filter

Q

Digital

Decimation

Filter

High

Pass

Filter

DAC

AINR

S/H

DAC

+

-

LP Filter

Q

Digital

Decimation

Filter

High

Pass

Filter

VA

3.3V - 5.0V

GND

VD

3.3V - 5.0V

Preliminary Product Information

www.cirrus.com

This document contains information for a new product.

Cirrus Logic reserves the right to modify this product without notice.

Copyright Cirrus Logic, Inc. 2004

(All Rights Reserved)

漏

AUG 鈥?4

DS608PP2
