High Current Bridge Rectifier
COMCHIP
www.comchiptech.com
KBPC Series
Reverse Voltage: 50 - 1000 Volts
Forward Current: 10/15/25/35/50 Amp
Terminals/Plastic
Lead/Plastic
Features
Surge overload 200 - 400 Amp peak
Low forward voltage dro
Mounting position: Any
Electrically isolated base - 1800 Volts
Solderable 0.25鈥?FASTON terminals
Materials used carries U/L recognition
Mechanical Data
Case:Epoxy Case with Heat Sink Internally
Mounted in the Bridge Encapsulation
Terminals: Plated Leads Solderable per
MIL-STD-202, Method 208
Mounting: Through Hole for #10 Screw
Weight: 30 grams (approx.)
KBPC
KBPC-W
Dim
A
B
C
D
E
G
H
TERMINALS
LEAD
Min
Max
Min
Max
28.40
28.70
28.40
28.70
10.97
11.23
10.97
11.23
15.70
16.70
17.10
19.10
17.50
18.50
10.90
11.90
22.86
25.40
30.50
-
Hole for #10 screw, 5.08脴 Nominal
6.35 Typic al
0.97脴
1.07脴
All Dimension in mm
Single In-Line/Plastic
KBPC-S
Dim
Min
Max
A
28.40
28.70
B
10.97
11.23
C
13.90
-
D
19.10
-
E
5.10
-
G
1.20 脴 Typical
H
3.05
3.60
All Dimensions in mm
- 鈥淪鈥?Suffix Designates Single In-Line
- 鈥淲鈥?Suffix Designates Wire Leads
- No Suffix Designates Faston Terminals
KBPC-S
MDS0304007A
Page 1
